AWS A5.16 ERTi-1 ERTi-7 2.0mm 2.4mm 3.2mm Titanium Welding Wire For Biomedical
試供品およびクーポンのための私に連絡しなさい。
whatsapp:0086 18588475571
WeChat: 0086 18588475571
Skype: sales10@aixton.com
心配があれば、私達は24時間のオンライン・ヘルプを提供する。
x商品の詳細
| 材料グレード | クラス 1-5 (米国),Ti Gr1-Gr5 (ヨーロッパ) | 転がりプロセス | 冷たいローリング |
|---|---|---|---|
| ワイヤーの直径 | 2.0mm 2.4mm 3.2mmなど | マテール | ERTI-1、ERTI-2、ERTI-5、ERTI-7 |
| ワイヤー表面 | 明るい表面 | キーワード | チタンの平面ワイヤ |
| 耐食性 | 素晴らしい | 状態 | コイルとストレート |
| 電気伝導率 | 適度 | 使用 | 採取/ガラス/医学/企業 |
| 技術 | コールドロールホットロール | 応用 | 溶接、3D印刷、航空宇宙、医療 |
| 表面 | 明るい | 表面仕上げ | 磨き 酸化 |
| パッケージ | 標準エクスポートパッケージ | ||
| ハイライト | AWS A5.16 チタンの溶接線,ERTi-1 バイオメディカル用溶接線,3.2mmチタン溶接線 |
||
製品の説明
Introduction
Gr1 Titanium Welding Wire is a commercially pure titanium wire containing a minimum of 99% titanium. It is the softest and most ductile of all titanium grades, making it easy to form into various shapes and sizes.
This wire is typically produced through a cold drawing process, where a titanium rod is pulled through a series of dies to reduce its diameter while improving mechanical strength and surface finish.
Thanks to its excellent corrosion resistance and high-temperature stability, Gr1 titanium wire is widely used in the chemical industry, particularly for equipment that operates under harsh conditions involving high temperatures, pressure, and corrosive media.
Specification
| Item | Details |
|---|---|
| Product Name | Titanium Welding Wire |
| Grades Available | Gr1, Gr2, Gr5, Gr7, etc. |
| Standards | ASTM B348, ASTM SB348, ASTM B863 |
| Size Range | Diameter: 0.1 mm – 6 mm |
| Surface Finish | Pickled, Polished |
| Process | Cold Rolled / Cold Drawn |
| Applications | Aerospace, Chemical Equipment, Medical Devices |
Chemical Composition (Typical for Grade 1)
| Element | N | C | H | Fe | O | Al | V | Ti | Other (max) |
|---|---|---|---|---|---|---|---|---|---|
| Content (%) | 0.03 | 0.08 | 0.015 | 0.18 | 0.20 | — | — | Balance | 0.4 |
Mechanical Properties
| Grade | Tensile Strength (min) | Yield Strength (0.2% offset) | Elongation (%) |
|---|---|---|---|
| KSI / MPa | KSI / MPa | ||
| Gr1 | 35 / 240 | 25 / — | — |
Applications
Chemical Equipment Fabrication
Used in the manufacturing of reactors, heaters, heat exchangers, storage tanks, and other components that operate under corrosive, high-temperature, and high-pressure conditions.
Equipment Connection and Repair
Essential for welding Gr2 titanium components, providing strong, corrosion-resistant joints in chemical and industrial systems.
Biomedical Devices
Increasingly used in orthopedic implants, dental prostheses, and cardiovascular components, due to its excellent biocompatibility, non-toxicity, and resistance to body fluids.
