Porous Sintered Metal Filter Tube SS 316L For Catalyst Recovery Chemical
試供品およびクーポンのための私に連絡しなさい。
whatsapp:0086 18588475571
WeChat: 0086 18588475571
Skype: sales10@aixton.com
心配があれば、私達は24時間のオンライン・ヘルプを提供する。
x商品の詳細
| 耐摩耗性 | 高い | 温度抵抗 | ≤400℃ |
|---|---|---|---|
| サンプル サービス | テストにサンプルを提供しなさい | 最大圧力 | 2.0Mpa |
| 材料 | SS 316L、チタン、Inconel600、Monel400、ETXC。 | その他のサービス | Platium、IrのRuのコーティングのチタニウムの版 |
| 表面処理 | 研磨 | ろ過エリア | 0.3-1.0m2 |
| アドバンテージ | 高孔隙性と透透性 | タイプ | チタンフィルター要素 |
| 圧縮強度 | ≥0.6MPa | フィルター評価 | 0.5um-50um |
| フィルターメディア | ニッケルの粉 | 労働生活 | 10年以上 |
| 温度 | 0-200℃ | ||
| ハイライト | シンター金属フィルターチューブ SS 316L,触媒復元用の多孔金属フィルター,化学薬品のためのシンタード孔隙フィルター |
||
製品の説明
Introduction
Compared with traditional filtration materials such as paper, cotton, PP, PE, PES, and PTFE, metal powder sintered porous materials offer superior performance.
They feature excellent permeability, uniform pore size and pore control, stable shape, high filtration accuracy, wear resistance, and outstanding mechanical strength.
Additionally, these materials exhibit good heat conduction, heat resistance, and dissipation performance, allowing them to be washed and reused multiple times without significant loss of performance.
Specifications
| Product Name | SS 316L Sintered Tube |
|---|---|
| Material | Pure Titanium / SS316L / Bronze |
| Size | OD 20–80 mm × WT 2.5–3.0 mm × L 10–1200 mm |
| Filter Accuracy | 0.5–80 µm |
| Connection | Customized according to customer requirements |
| Applications | Sparging, Separation and Filtration, Carbonation, Liquid Filtration, etc. |
Technical Parameters
| Filter Accuracy (µm) | Porosity (%) | Permeability (m³/m²·h·kPa) | Compression Strength (MPa) | Temperature Tolerance (°C) | Max Working Pressure (MPa) |
|---|---|---|---|---|---|
| 0.5–50 | 20–50 | 3–800 | 2–3 | 250 | 0.6 |
Performance Features
Excellent mechanical strength and structural stability
Uniform pore size distribution and good air permeability
Superior chemical stability and corrosion resistance
High temperature resistance (up to 250 °C)
Acid and alkali resistance
Fireproof, anti-static, and reusable
Long service life with consistent filtration efficiency
Application Environments
Suitable for use in environments containing:
Nitric acid, sulfuric acid, acetic acid, oxalic acid, phosphoric acid, 5% hydrochloric acid, molten sodium, liquid hydrogen, liquid nitrogen, hydrogen sulfide, acetylene, water vapor, hydrogen gas, coal gas, carbon dioxide gas, and other chemically aggressive media.
Widely used in:
Catalyst recovery and chemical processing
Beverage and food production
Metallurgy and refining
Coarse and fine liquid filtration
Dust and oil mist removal from gases and vapors
Sound attenuation, flame retardancy, and gas buffering applications
